Type: Separable Elbow Connector Voltage: 15kV/24kV/35kV
High Light:

coupling connector

,

straight connector

We are manufacturer for Separable Elbow Connector

250A IEC Series

250A, 15kV and 24kV Class Elbow Connector



Application:



Chuangyin® Separable Elbow Connector is widely applicable for connecting XPLE cable to equipment, including transformers and switchgears in 250 A power network.

Cable section: 25 to 120 mm2

Voltage rating: 6/10 (12) kV, 6.35/11 (12) kV, 8.7/15 (17.5) kV, 12/20 (24) kV, 12.7/22 (24) kV

The interface designed to comply with EN 50180 / EN 50181 250 A interface type A and HD 629.1, IEC 60502.4, GB/T 12706.4 etc.



Features:

Made of high quality EPDM rubber

Fully shielded and submersible

Compact design

Voltage class: 15 kV, 24 kV

100% factory tested

In compliance with HD 629.1, IEC 60502.4



Construction:

1. Probe

2. Semi-conducting Insert

3. Insulating Layer

4. Operating Eye

5. Stress Cone

6. Cable Entrance

7. Grounding Tab

8. Semi-conducting Shield

9. Lug



Technical Data:

Item Parameters
Voltage Class 15 kV 24 kV
Rated Current 250 A 250 A
AC Withstand Voltage 5 min 39 kV 54 kV
DC Withstand Voltage 15 min 35 kV 48 kV
Partial Discharge 15 kV, ≤10 pC 20 kV, ≤10 pC
BIL 95 kV 125 kV
Thermal Current 10 kV, 0.8 s 10 kV, 0.8 s
Dynamic Current 20 kA, 10 ms 20 kA, 10 ms
Cable Section 25-120 mm2 35-120 mm2
Interface Type A A



Kit Contents:

Elbow Connector

Lug

Probe

Bail Assembly

Wrench

PVC Tape

Sand Bar

Silicone Grease

Wipers

Tape

Installation Instruction



Ordering Instructions:

Part Number Cable Section (mm²) Diameter over Insulation (mm) Code
CYSESZT-15/250-25 25 16.3-17.8 A
CYSESZT-15/250-35-50 35-50 17-20 B
CYSESZT-15/250-70-95 70-95 20-23.1 C
CYSESZT-15/250-120 120 23-24.6 D
CYSESZT-24/250-35-50 35-50 19-22 A
CYSESZT-24/250-70-95 70-95 22-25.1 B
CYSESZT-24/250-120 120 25-26.6 C

Remarks:

Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.

The quality is assurance, the reasonable price, welcome to order, ordering or the proxy.
