| Place of Origin: | ShenZhen |
| Brand Name: | Chuangyin |
| Certification: | Test Report |
| Model Number: | JDZ(X)W3-17.5 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Carton packing for one sets, one set including three piece with Components |
| Delivery Time: | Within 7 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 36,000,00pcs per year |
| Construction: | Full Enclosed | Type: | Epoxy Resin |
|---|---|---|---|
| Rated Frequency: | 50/60HZ | Highest Voltage: | 24KV |
| Package 3pcs/Plywood: | 1170*470*850 | Net Weight: | 44.5KG/3pcs |
| High Light: | medium voltage potential transformer,single phase voltage transformer |
||
Instrument Current Transformer Electric Combined Instrument Transformer/ Sensor FLPIT
1. Introduction:
Epoxy resin casting and full enclosed construction, is used outdoor for measuring voltage, electric energy and protective relaying in single-phase or three-phase AC circuit with the frequency 50Hz or 60Hz and highest voltage for equipment 17.5kV.
The product has the feature of anti-pollution, large creepage distance of external insulation and maintenance free.
2. Technical Data:
Rated insulation level: 17.5/38/95kV,24/50/125kv
Rated frequency: 50/60Hz
Installation site: Outdoor
Technical standard accords with: IEC 60044-2
IEC 61869-1&3
Technical Data:
| Item | Specification | Unit | Data | Remarks |
| 1 | Um | kV | 17.5 | 24 |
| 2 | Rated Insulation Level | kV | 17.5/38/95 | 24/50/125 |
| 3 | Rated Primary Voltage | V | 12470/ ꇌ3,13800 /ꇌ3 |
20000ꇌ3 22000/ꇌ3 |
| 4 | Rated Secondary Voltage | V | 100 ꇌ3,110 ꇌ3,100/3,110/3 | |
Outline drawing:
